BCH0030LCACZA0200 Condensing Unit
3 HP Low Temp System
The Heatcraft BCH0030LBACZA0000 is a condensing unit suitable for outdoor air cooling, designed for medium temperature applications. This unit has a three horsepower motor and operates at a voltage of 208-230 volts with single phase. It features a scroll compressor, making it efficient for various refrigeration needs.
- Comes with a defrost timer, pressure control valves, and a receiver.
- Includes liquid line drier and sight glass for enhanced performance.
$6,674.76
Split System:
- Based on No of Systems : 1
- Room Temp : -10 °F
- Evap TD : 9.83
- Line Loss : 2
- Balanced Capacity : 8257.0 BTU/H
- Run Time : 17.44 Hours
- Refrigerant Type : R448A
- CU BN SCRL 3.0HP 208-230/1/60 LOW
- Ambient Temp : 105 °F
- Suction Temp : -21.83 °F
- Voltage : 208-230/1/60
AWEF Value : 3.15
- UC B LP EL 2F 230 1PH E RTE M 8
- Evap. Temp : -21.83 °F
- Voltage : 208-230/1/60
- Cooler AWEF > 32 : N/A
- Freezer AWEF <= 32 : 4
